Heath Robinson runs again

Reconstruction of the machine that inspired Colossus unveiled

Courtesy of the Heath Robinson Museum in Pinner, a temporary exhibition of W Heath Robinson at War humorous illustrations was also opened and can be seen by the public six days a week during the Museum ‘s new extended open hours.

Irene Dixon with Peter Higginson in the W Heath Robinson exhibition. (Photo Courtesy of TechnoVisual)

Irene Dixon with Peter Higginson in the W Heath Robinson exhibition. (Photo Courtesy of TechnoVisual)

The Heath Robinson machine was an early attempt to automate codebreaking during the Second World War. It was designed to tackle the hugely complex Lorenz cipher, used by Hitler and his generals to communicate strategic messages.

The complexity of the codebreaking machine resulted in its being named in honour of W Heath Robinson the illustrator, but he would never have known of this tribute because he died long before the secrecy surrounding Bletchley Park codebreaking was lifted.

In unveiling the Heath Robinson machine and opening the Heath Robinson at War exhibition, Irene Dixon, former Colossus Wren, said, “It is such a delight to see this incredible reconstruction of the Heath Robinson machine. It is a fantastic achievement and good to meet Peter too whose great uncle made us laugh with his comical cartoons.

“Seeing all this brings back many memories of my arrival at Bletchley Park in late 1943 to work on the new Colossus machine. I was able to see Wrens working on the original Heath Robinson. It produced good results, but the tapes broke so often that it was a major job to repair them. That was a tedious full-time glue job for somebody! In later years I was able to reassure a former Wren that she had been doing valuable war work!”

Peter Higginson, Margaret Sale and Irene Dixon by the Heath Robinson machine. Photo courtesy of Andy Taylor.

Peter Higginson, Margaret Sale and Irene Dixon by the Heath Robinson machine. Photo courtesy of Andy Taylor.

Peter Higginson, art historian and great nephew of William Heath Robinson, said, “If William Heath Robinson had known about the codebreaking machine named in his honour, it would have extended his career. He was deeply aware of modernity and brought out the humour in it to give it humanity.

“Undoubtedly the 1940s team who named the codebreaking machine were deeply serious and committed but they identified with this humorous approach to technology rather than characterising it as a robotic device devoid of humanity.”

After the unveiling, reconstruction team members Phil Hayes and John Pether set the reconstructed Heath Robinson running once again, more than seven decades after the original first helped break Lorenz ciphers. TNMOC volunteer Helen Jarvis re-enacted the wartime Wren’s task of reading the results from a dashboard.

Phil Hayes introduces the reconstructed Heath Robinson. Photo Courtesy of Andy Taylor

Phil Hayes introduces the reconstructed Heath Robinson. Photo Courtesy of Andy Taylor

Paying tribute to the team of volunteer engineers who reconstructed the Heath Robinson, Andrew Herbert, chair of TNMOC, said, “After seven years of skilled work by TNMOC volunteers, the public can see a Heath Robinson working – for the first time! It is an incredible achievement, adding yet more life to the story of Lorenz codebreaking at The National Museum of Computing. Visitors can now see the original German cipher machines alongside working reconstructions of the whole of the deciphering process from intercept to decrypt.”

Like the historic machines throughout the Museum, the Heath Robinson original illustrations are protected by the newly installed Paessler AG environmental monitoring system.

Notes To Editors

1 The Heath Robinson machine and its links to Colossus

The Heath Robinson machine was commissioned by the Newmanry which under Max Newman was attempting to automate codebreaking. The original machine was built mostly at the Telecommunications Research Establishment at Malvern. It became operational at Bletchley in June 1943 and was successful, but its limitations soon became apparent. It proved extremely difficult to keep its two tapes running in synchronisation, it required too many tape changes to tackle all but five of the Lorenz wheel patterns, it was not scalable and it required very high maintenance.

Tommy Flowers of the GPO laboratories in Dollis Hill, London, was asked if he could improve upon the Heath Robinson, but rather than modify it, Flowers proposed the development of Colossus to overcome the Heath Robinson limitations. Flowers’ use of valves in place of the synchronising tape on the Robinson was a vital breakthrough.

Even after the deployment of Colossus in February 1944, the Heath Robinson continued to be developed and used in tackling the Lorenz cipher. By the end of the war, two ‘Super Robinsons’ were operational and another two under development.

After the war, one Super Robinson went to Eastcote and was probably operational until 1950s. Further development after the war led to Colorob, a combination of Robinson and Colossus, which became operational in 1955.

2 The Heath Robinson at War Exhibition

An exhibition of original Heath Robinson wartime illustrations will be on display until 30 June, courtesy of the Heath Robinson Museum in Pinner, London.

3 About The National Museum of Computing

Now fully open Tuesdays to Sundays, 10.30 am to 5.00 pm.

The National Museum of Computing, located on Bletchley Park in Block H, one of England’s ‘irreplaceable places’, is an independent charity housing the world's largest collection of functional historic computers, including reconstructions of the wartime code-breaking Colossus and the Bombe, and the WITCH, the world's oldest working digital computer. The Museum enables visitors to follow the development of computing from the ultra-secret pioneering efforts of the 1940s through the large systems and mainframes of the 1950s, 60s and 70s, and the rise of personal computing in the 1980s and beyond.

The Museum runs a highly successful Learning Programme for schools and colleges and promotes introductions to computer coding amongst young people to inspire the next generation of computer scientists and engineers.

Sponsors of the Museum have included Bletchley Park Science and Innovation Centre, Fujitsu, InsightSoftware.com, Paessler AG, Sophos, Issured, Lenovo, Bloomberg, Ocado Technology, Ceravision, CreateOnline, 4Links, Google UK, IBM, NPL, HP Labs, FUZE and BCS.

The whole Museum is open to the public Tuesdays to Sundays, 10.30 am - 5 pm. Public and private Guided Tours are available and bookable online – see the website for details. Educational and corporate group visits are available by prior arrangement.

For more information, see www.tnmoc.org and follow @tnmoc on Twitter and The National Museum of Computing on Facebook.
